High speed and eccentric working torques for strong vibration. Wide range.
Properties
- Lubrication-free
- Low noise level
- Strong vibration by means of high speed and eccentric working torques
- Rated frequency 6,000 – 46,000 rpm
- Centrifugal force 130 – 12,000 N
- Continuously variable
- Can be used up to 150°C
- Resistant to extreme environmental conditions
Field of application
- Emptying of bunkers
- Screen filters
- Vibrating tables
- Preventing adhesion in pipelines and silos
- Transporting of fine powders
- Moving of bulk materials
The vibrator operates in 2 or 6 atmospheres with the following performance
| vibrations/min | centrifugal force Ν | air consumption l/min | |||
| 2bars | 6bars | 2bars | 6bars | 2bars | 6bars |
| 17.000 | 23.000 | 2.170 | 5.520 | 185 | 455 |
Upon Order
| A | width | C | D | E | F | G/H |
| mm | mm | mm | mm | mm | mm | |
| 80 | 56 | 128 | 104 | 16 | 9 | 1/4″ |
| Weight | 1,08 kg |
|---|---|
| Series | |
| Company | |
| Delivery | Upon Order |
